How to achieve precise 50 Ω or 75 Ω impedance matching between antenna connectors and transmission lines through structural design and material selection? What are the key factors across different frequency bands?

Precise impedance matching is achieved via “accurate structural design + appropriate material selection”, with frequency-dependent key factors focusing on dimensional tolerances and dielectric properties.

Structural design considerations for accurate impedance matching

1. Transmission line optimization:

• Coaxial cables must strictly control inner conductor diameter, outer conductor inner diameter, and dielectric thickness.
• Typical 50 Ω coax: inner/outer conductor diameter ratio ≈ 1:2.3
• Typical 75 Ω coax: inner/outer conductor diameter ratio ≈ 1:3.5
• Microstrip lines require precise line width and substrate thickness design; line width tolerance should be ≤ ±0.01 mm.

2. Connector structural adaptation:

• Choose connectors matching the transmission line impedance (e.g., SMA → 50 Ω, BNC → 75 Ω).
• Ensure smooth transition between connector inner conductor, ground structure, and transmission line; avoid steps or gaps that cause impedance discontinuities.

3. Transition design:

• Use gradual impedance transitions at connector–line interfaces to reduce reflections.
• In high-frequency applications, add compensation sections to offset parasitic effects at the connection point.

Key material selection requirements

1. Dielectric material:Prefer materials with stable dielectric constants.

• 50 Ω high-frequency: PTFE (ε_r = 2.1), FEP (ε_r = 2.1)
• 75 Ω low-frequency: PE (ε_r = 2.3)
• Avoid dielectric constant fluctuations that cause impedance drift.

2. Conductive materials:

• Connector inner conductors: gold-plated brass (≥0.8 μm)
• Outer conductors: tin-plated copper or stainless steel
• Transmission line inner conductors: high-purity copper to reduce conductor loss and maintain impedance stability.

3. Material consistency control:

• Ensure batch-to-batch dielectric constant variation ≤ ±0.05
• Keep conductor resistivity within specified tolerance ranges.

Key factors by frequency band

1. Low frequency (<1 GHz):

• Mainly affected by structural dimensional tolerances (inner/outer conductor diameters, connector gaps)
• Ensure precise physical contact between conductor surfaces
• Dielectric temperature stability is less critical

2. Mid frequency (1–10 GHz):

• Both structural tolerances (≤ ±0.02 mm) and dielectric stability influence performance
• Connector ground structure design must minimize parasitic inductance

3. High frequency (>10 GHz):

• Parasitic parameters dominate (dielectric loss, connector pin parasitic capacitance)
• Frequency-dependent dielectric constant must be carefully considered
• PCB layout should be optimized to reduce signal crosstalk
